Dewalt DCMPS520N-XJ Pruning Saw 18V Bare Unit | DEWMPS520N

• DeWalt DCMPS520N 18V XR cordless brushless pruning saw bare unit
• 20cm (8 inch) bar with 8.6 m/sec chain speed for fast, clean cuts
• Brushless motor delivers up to 70 cuts per charge on a single battery
• Automatic oiling system lubricates chain during use, reducing maintenance
• 2.08kg bare weight, 61% lighter and 3x more compact than the DCCS620
• Metal pruning tip guard provides stability and safety during upcuts
• Two handles with hand protection and safety switch-on lock
• Metal kick-back guard protects chain from dirt and fences
• Bolt lock chain tensioning with onboard wrench stored inside bar cover
• Variable throttle switch for full performance control
• Compatible with all DeWalt 18V XR and FlexVolt battery packs
• Bare unit: no battery or charger included

DeWalt DCMPS520N 18V XR Brushless Pruning Saw with 20cm Bar, Auto Oiler, and 70 Cuts Per Charge

20cm bar with brushless motor delivers up to 70 cuts per charge:

The DeWalt DCMPS520N is a compact, cordless pruning saw designed for professional tree care, garden maintenance, and landscaping work. The high-efficiency brushless motor maximises runtime and motor life, delivering up to 70 cuts per charge through 4x4 inch pressure-treated pine on a single DeWalt 18V battery (sold separately). The 20cm (8 inch) bar and 8.6 m/sec chain speed provide fast, clean cuts through branches, deadwood, thick brush, and bundled wood. The continuously variable throttle switch gives you full control over cutting speed for different branch thicknesses and timber types.

Automatic oiling and bolt lock tensioning for low-maintenance operation:

The automatic oiling system lubricates the chain and bar during use without manual intervention, reducing friction, extending chain life, and keeping cuts smooth. The bolt lock chain tensioning system provides reliable bar retention, and the onboard wrench is stored conveniently inside the bar cover so it is always to hand for tensioning adjustments in the field. These features reduce downtime and maintenance requirements compared to manually oiled pruning saws.

2.08kg lightweight with dual handles and safety features:

At just 2.08kg without battery, the DCMPS520N is 61% lighter and 3 times more compact than the DeWalt DCCS620 chainsaw, significantly reducing fatigue during extended pruning sessions, overhead cutting, and work at height. Two handles with additional hand protection provide secure grip and control. The safety switch-on lock prevents accidental activation, the metal kick-back guard reduces the risk of contact with fences, walls, and obstacles, and the integrated metal pruning tip guard provides stability during upcuts.

Part of the DeWalt 18V XR cordless system:

The DCMPS520N is compatible with all DeWalt 18V XR and FlexVolt battery packs, allowing you to share batteries across your existing DeWalt cordless tool collection. This bare unit ships without a battery or charger. The compact design allows easy access to tight spaces between branches, against fence lines, and in dense canopy areas where full-size chainsaws cannot reach.

Shop garden and outdoor products from Heavins.ie:

DeWalt garden power tools, pruning saws, and cordless outdoor equipment. In stock with fast nationwide delivery across Ireland. Browse our full garden and outdoor range for complete garden power tool solutions.

Key Features

• 20cm (8") bar: Compact for pruning, trimming, and cutting in tight spaces.

• 8.6 m/sec chain speed: Fast, clean cuts through branches and brush.

• Brushless motor: Longer runtime, efficient power, extended motor life.

• Up to 70 cuts per charge: On 4x4" pressure-treated pine per battery.

• Automatic oiler: Lubricates chain during use, reduces maintenance.

• 2.08kg bare weight: 61% lighter and 3x more compact than DCCS620.

• Metal pruning tip guard: Stability and safety during upcuts.

• Dual handles with hand protection: Secure grip and control.

• Safety switch-on lock: Prevents accidental activation.

• Bolt lock chain tensioning: Onboard wrench stored in bar cover.

• Variable throttle: Full control over cutting speed.

• 18V XR system: Compatible with all DeWalt 18V XR and FlexVolt batteries.


Specifications

• Brand: DeWalt
• Model: DCMPS520N-XJ
• Type: 18V XR Brushless Cordless Pruning Saw (bare unit)
• Voltage: 18V
• Motor: Brushless
• Bar Length: 20cm (8 inches)
• Chain Speed: 8.6 m/sec
• Cuts Per Charge: Up to 70 (on 4x4" pressure-treated pine)
• Oiling: Automatic
• Chain Tensioning: Bolt lock with onboard wrench
• Safety: Switch-on lock, metal kick-back guard, metal pruning tip guard
• Handles: Two handles with hand protection
• Throttle: Continuously variable
• Battery Compatibility: DeWalt 18V XR and FlexVolt
• Weight (without battery): 2.08kg
• Replacement Bar: DT20694 (20cm)
• Replacement Chain: DT20693 (20cm)
• EAN: 5035048821404
• Warranty: 1 Year

What's Included in the Box

• DeWalt DCMPS520N 18V XR Pruning Saw (bare unit)
• 20cm pruning bar (DT20694)
• 20cm chain (DT20693)
• Bar cover
• Onboard wrench

Setup and Care

Bar, chain, and battery installation:

Attach the 20cm pruning bar and chain following the user manual instructions. Use the onboard wrench (stored inside the bar cover) to tension the chain to the correct tightness: the chain should be snug against the bar with enough slack to pull away slightly by hand. Fill the automatic oiler reservoir with bar and chain oil. Slide a charged DeWalt 18V XR or FlexVolt battery onto the base of the saw until it clicks into place.

Cutting technique and safety:

Grip both handles firmly, activate the safety switch-on lock, and squeeze the variable throttle to start the chain. Allow the chain to reach full speed before making contact with the branch. Let the chain do the cutting work without forcing the bar through the timber. For larger branches, use an undercut first (cutting upward from below) to prevent the branch tearing bark as it falls, then complete the cut from above.

Chain tensioning and automatic oiler maintenance:

Check chain tension before each use and after every 10-15 minutes of cutting. A correctly tensioned chain sits snug against the bar without sagging. The automatic oiler lubricates the chain during operation, but check the oil reservoir level before each session and refill with bar and chain oil as needed. The metal pruning tip guard helps maintain stability when performing upcuts.

Cleaning, storage, and chain replacement:

After use, wipe the bar, chain, and body with a dry cloth to remove sap, sawdust, and moisture. Fit the bar cover for safe storage. Store in a dry location. Remove the battery when not in use for extended periods. Replace the chain (DT20693) when it no longer cuts efficiently after sharpening, and replace the bar (DT20694) if it shows visible wear, bending, or groove damage.
