EVO PRO-A 4K @ 60Hz HDR HDMI Splitter with Downscaling | 775736

• Splits one HDMI source to two TVs or displays at once
• 4K@60Hz HDR output with 18 Gbps bandwidth
• Downscaling: run one screen at 4K and one at 1080p simultaneously
• HDCP 2.3 and EDID support for protected and varied content
• CEC pass-through for HDMI device control
• LPCM, DTS Digital, and Dolby Digital audio supported
• Compact 85 x 85 x 18 mm body, weighs just 42 g
• MicroUSB powered - cable included, standard 5V 1A supply required
• Dimensions: 85 x 85 x 18 mm

GBC EVO PRO-A HDMI Splitter with 4K@60Hz, HDR and Downscaling

One Source, Two Screens:

The GBC EVO PRO-A takes a single 4K@60Hz HDR HDMI source and distributes it to two displays at the same time. Whether you have two televisions in the same room or need to run a second screen in an adjoining space, this splitter handles both outputs simultaneously without the need for a second source device.

Downscaling for Mixed-Resolution Setups:

The built-in Downscaling function means that if one of your displays is only capable of 1080p Full HD, the EVO PRO-A will reduce the output resolution on that port automatically. One screen can receive the full 4K signal while the other receives a 1080p version of the same content — both playing simultaneously from the same source.

Broad Format and Audio Compatibility:

With 18 Gbps bandwidth and Deep Colour support at 36 bit, the EVO PRO-A handles HDR content without compromise. HDCP 2.3 and EDID support ensure compatibility with protected content and connected display types, while CEC support allows device control to pass through over HDMI. Audio formats supported include LPCM, DTS Digital, and Dolby Digital.

Compact and Low-Cost to Run:

The unit measures just 85 × 85 × 18 mm and weighs 42 g, so it sits neatly behind a TV or in an AV cabinet without taking up space. It is powered via the included MicroUSB cable using a standard 5V 1A supply — a phone charger or USB port will do the job. The power adapter itself is not included in the box.

Shop the Entertainment range from Heavins.ie for cables, adaptors, and TV accessories delivered across Ireland.

Key Features

1 Input, 2 Outputs - distributes one HDMI source to two displays simultaneously.
4K@60Hz HDR Support - handles 4K Ultra HD content at 60 frames per second with HDR.
Downscaling - automatically reduces output resolution on lower-spec displays; one port can run 4K while the other runs 1080p.
18 Gbps Bandwidth - sufficient for 4K@60Hz 4:4:4 colour space without signal degradation.
Deep Colour - supports 36-bit colour depth for richer image rendering.
HDCP 2.3 - compatible with the latest content protection standard for streaming and Blu-ray sources.
EDID Support - manages display handshaking to ensure stable connections with each output screen.
CEC Support - allows device control commands to pass through the HDMI connection.
Audio Formats - supports LPCM, DTS Digital, and Dolby Digital audio pass-through.
MicroUSB Powered - runs off any standard 5V 1A supply; MicroUSB cable included.

Specifications

• Brand: GBC
• Model: EVO PRO-A
• Manufacturer Part Number: 14281102
• Inputs: 1 x HDMI
• Outputs: 2 x HDMI
• Maximum Resolution: 4K@60Hz 4:4:4
• HDR Support: Yes
• Downscaling: Yes
• Bandwidth: 18 Gbps
• Deep Colour: 36 bit
• HDCP: 2.3
• EDID Support: Yes
• CEC Support: Yes
• Audio Formats: LPCM, DTS Digital, Dolby Digital
• Maximum Input Cable Length: 3 m
• Maximum Output Cable Length: 3 m
• Power Supply: 5V 1A via MicroUSB (adapter not included)
• Colour: Black
• Body Material: Plastic
• Dimensions (WxDxH): 85 x 85 x 18 mm
• Weight: 42 g
• EAN: 8023389775729
• Warranty: 1 Year

What's Included in the Box

• GBC EVO PRO-A HDMI Splitter
• MicroUSB power cable
